Product Description
VDI Form E3 50mm SH CNC Lathe ER40 Collet Chuck 53. 5040
USA MADE
Specs:
Shank Diameter (mm) 50.00
Maximum Cutting Tool Size (mm) 40.00
Projection (mm) 61.00
VDI Form Type E3
Through Coolant (Yes/No) Yes
Collet Series ER40
Shank Thread Size 5/8-18
CNC toolholders are available for Mazak, Emco-Maier, Hitachi, Seiki & Okuma machines.
All Toolholders are precision ground, fully case-hardened and coated with a black-oxide finish for long lasting protection.
Material 8620 Alloy Steel manufactured to meet DIN 69 880 specifications.
AJAX has a complete line of Static CNC Lathe VDI Toolholders made to DIN 69880 standards.
All VDI Tool Holders are made to ISO 9001/2000 specifications.
Available in All Metric VDI Shank Sizes: 16mm, 20mm, 25mm, 30mm, 40mm, 50mm, 60mm & 80mm.
Holds Standard Inch Size Tooling; Metric Available Upon Request.
VDI is a Quick Change Toolholding System.
VDI Provides a fast and accurate way of affixing tools to the Turret; Tool Changes are performed in seconds.
Toolholders can be Preset. A Cam Operated Clamping System. AJAX offers a complete line of Live Tooling & Live Tooling Repair.
Nakamura Style VDI Also available.
Toolholders can be manufactured to meet your specifications. (inch or metric sizes)
ADDITIONAL SIZES:
VDI Shank Size Part Number
20MM 53. 2016
25MM 53. 2516
30MM 53. 3020
40MM 53. 4025
50MM 53. 5032
60MM 53. 6032
