TMX 5" Set Tru Forged Lathe chuck Made In Poland

SET-TRU Forged Steel Chucks with Fine Adjustment

3-Jaw Chuck with Two-Piece Hard Reversible Jaws

• 3 Pinion Design

• 0.0006" T.I.R. Repeatability

Made in Poland available in many sizes

Each chuck is provided with:

• 1 Set of hard master jaws

• 1 Set of hard top reversible jaws

• 1 Chuck wrench

• 1 Set of mounting bolts

• 1 Set of fine adjustment screws

• Eye bolts for chuck sizes 16" and larger

TECHNICAL DATA

Chuck Type 3-Jaw Scroll

Chuck Size in 5

Material Forged Steel

Jaw Type 2 Piece

Mount Type Front

Gripping Force (daN) daN 2400

Gripping Force (lbf) lbf 53

Torque on Wrench lbf*ft 298

Maximum Speed RPM 3800

d1 min in 0.1181

d1 max in 1.9685

d2 min in 2.0472

d2 max in 3.7795

d3 min in 3.7402

d3 max in 4.9213

d4 min in 1.3386

d4 max in 2.9921

d5 min in 3.7402

d5 max in 4.9213

Weight 11 lbs
