Indexable Drill .812" Coolant Thru 4xD Shank Drilling
Product Description
Steel 4xD Indexable Drill with a .812″ Diameter 3.761″ Drill Depth .750″ Shank Length to hold (2) WCMX 21.52 Coolant Thru
Product Specs
BD (Body Diameter) 1.22
DC (Cut Diameter) 0.812
DCONms (Connection Diameter) 0.75
L (Overall Length) 6.763
LF (Functional Length) 3.761
LPR (Protruding Length) 4.763
LS (Length of Shank) 2
LU (Usable Length) 3.248
Product Specs
BD (Body Diameter) 1.22
DC (Cut Diameter) 0.812
DCONms (Connection Diameter) 0.75
L (Overall Length) 6.763
LF (Functional Length) 3.761
LPR (Protruding Length) 4.763
LS (Length of Shank) 2
LU (Usable Length) 3.248
