Vertex 8" Horizontal/Vertical Super Indexing Spacer JJ55CS8

Vertex 8" Horizontal/Vertical Super Indexing Spacer JJ55CS8

Item# JJ55CS8ajaxind
$1,764.95
Availability: In Stock
Vertex 8" Horizontal/Vertical Super Indexing Spacer JJ55CS8

Product Description



Technical Specifications

Dividing Accuracy 40"

Parallelism .0004

Description 8" Horiz/Vert Super Spacer

Size 8

Weight 174 lbs

Complete with a 3-jaw chuck and faceplate.

Maximum individual spacing error is 25 seconds.

Squareness (table base to chuck 90°) is 0.0008".

Base parallelism from face to face is 0.0004".

Mounting flange concentricity is 0.0008".

Chuck concentricity is 0.0005".

Chuck has top reversible jaws.

Gear ratio is 1:90.

Vertex # CS-8

This index combines the advantages of the Simple Index with those of a worm-geared index.

When mounted on a milling, boring, or other machine tool, it can carry out single-purpose indexing and indirect indexing using the worm-drive mechanism.

Disengaging the worm drive, the 24-notch master plate permits 2, 3, 4, 6, 8, 12 and 24 dividing in the same manner as the Simple Index.

When the chuck is removed the unit can be used as a horizontal and vertical type rotary table. The operating handle to rotary table worm gear reduction ratio is 1:90. The operating handle collar is graduated in one minute, and readings down to ten seconds can be set on the Vernier.

Made In Tawain

This index complete with 8" 3-jaw chuck; 2-pc. hardened and reversible jaw; 10" face plate and 6 masking plates

Optional Tailstock for Super Spacer- For 10 & 12" Table P/N: JJ55TS3

Optional Dividing Plates - For LG 8, 10, 12 & 14" Table P/N: JJ55DP10
